Abstract
Severe acute respiratory syndrome coronavirus 2 (SARS-CoV-2) infection often causes coagulation disorders that affect highly vascularized organs, such as the lungs and kidneys.
The objective of this study was to report the histopathological findings of variations in the fibrin pattern of pulmonary and renal microthrombi in patients who died from SARS-CoV-2 infection.
Minimally invasive autopsies were performed on 40 patients to collect lung (n=40) and kidney (n=16) tissue samples. Histochemical and immunohistochemical staining techniques were used for histopathological analyses. Premortem laboratory data were obtained from the patients' electronic medical records.
The lung tissue showed a patchy pattern, characterized by areas of both minimal and severe damage. The most significant histopathological finding was the detection of thrombi with fibrin structures organized into discrete star-shaped units, which were more frequently observed in areas with severe lung injury than in those with minimal lung injury (p = 0.012). Star-shaped fibrin structures were also observed in the renal glomerular capillaries. Immunohistochemical staining revealed the presence of platelets and the procoagulant proteins von Willebrand factor (VWF) and Factor VIII within the star-shaped fibrin thrombi. Patients with star-shaped fibrin thrombi had higher levels of the systemic inflammatory indicators C-reactive protein (CRP) and neutrophil-to-lymphocyte ratio (NLR).
Our observations suggest that the inflammatory microenvironment resulting from SARS-CoV-2 infection may contribute to the formation of star-shaped fibrin units in the pulmonary and renal microthrombi.
Author Contributions
Copyright© 2024
Meneses-Flores Manuel, et al.
License
This work is licensed under a Creative Commons Attribution 4.0 International License.
This is an open-access article distributed under the terms of the Creative Commons Attribution License, which permits unrestricted use, distribution, and reproduction in any medium, provided the original author and source are credited.
Competing interests The authors have no conflicts of interest to declare.
Funding Interests:
Citation:
Results
The study population comprised 40 subjects, including 8 females and 32 males, with mean ages of 62.6 ± 9.7 years and 57.9 ± 15.5 years, respectively. All the patients were infected with SARS-CoV-2. Fibrin thrombi were identified in 33 out of 40 patients (82.5%), and bacterial co-infections were detected in 33/40 (70%) of the cases ( The most common comorbidities in the population were systemic arterial hypertension, diabetes mellitus, acute kidney injury, and obesity ( Abbreviations *Thrombi Non detectado; ** mean ± standard deviation; CAI - Community-acquired co-infection; HAI - Hospital-acquired co-infection; PWO co-infection - Patients without co-infection; DM - Diabetes mellitus; SAH - Systemic arterial hypertension; AKI - Acute Kidney Injury; BMI - Body Mass Index. In light of the study's primary objective, which was to examine the structural pattern of fibrin in thrombi, patients with thrombi were classified into two groups, designated as the "Star-shaped pattern" and the "Reticular pattern" ( Abbreviations: PT - Prothrombin time; INR - International normalized ratio; aPTT - Activated partial thromboplastin time; TT - Thrombin time; CRP - C-reactive protein; NLR - Neutrophil-to-lymphocyte ratio; PaO₂/FiO₂ - Ratio of arterial partial pressure of oxygen to the fraction of inspired oxygen; Sat O₂ - Oxygen saturation. Note: p-values marked in bold are statistically significant. The lung tissue showed a patchy pattern, including areas with minimal and severe damage, separated by the interlobular septum. In areas exhibiting severe damage, interstitial thickening, edema, and inflammatory infiltrates, comprising neutrophils and lymphocytes, were observed. In contrast, regions exhibiting minimal damage displayed a paucity of the previously listed histopathological findings ( Histopathological examination of renal tissue revealed tubular degenerative changes and glomerular damage. Fibrin thrombi were identified in 12/16 (75%) analyzed cases. These thrombi were predominantly located in peritubular (10/12) and glomerular (8/12) capillaries. The fibrin structure observed in renal thrombi was mostly fibrillary. However, in 4/12 (33%) cases, star-shaped fibrin structures were found in the glomerular and peritubular capillaries ( The star-shaped fibrin structure is a conglomerate of discrete fibrin units, each consisting of a spheroid core, with fine fibrin needles radiating from it. The core had an irregular size with an average diameter of 4 µm. The overall size of the structure ranged from 12 to 15 µm. Thrombi with this fibrin pattern were observed more frequently in blood vessels located in areas of severe lung damage (1.04 ± 0.7 vessels/mm²) compared to areas of minimal damage (0.33 ± 0.3 vessels/mm²) (p = 0.012). In areas of minimal damage, this fibrin pattern was observed only in paraseptal pulmonary capillaries adjacent to areas of severe damage.
Fibrin structure in thrombi
Star-shaped
RTP
Thrombi
ND*
Total
p
Patients (n)
7
26
7
40
Age (yr)**
65.9.3 ± 13.8
57.1 ± 13.5
52.7 ± 18.1
55.5 ± 14.9
0.224
females
2
5
1
8
males
5
21
6
32
Fibrin thrombi + (%)
100
100
0
82.5
Hospital stay (d)**
11.3 ± 5.8
17.1 ± 11.3
14.6 ± 4.1
15.0 ± 9.9
0.367
Co-infection (%)
CAI
14.3
11.5
42.9
17.5
HAI
57.1
57.7
28.6
52.5
PWO co-infection
28.6
30.8
28.6
30
Total
71.4
69.2
71.4
70
Comorbidities (%)
DM
28.6
38.5
28.6
35
SAH
42.9
38.5
42.9
40
AKI
14.3
30.8
28.6
27.5
BMI**
32.9 ± 6.2
32.7 ± 8.2
27.7 ± 0.5
32.4 ± 7.6
0.251
Parameters
Normal Range
Fibrin Patern
P values
Star-shaped
Reticular
n
N/A
7
26
N/A
PT (sec)
10.2 - 13.2
16.2 ± 2.4
16.3 ± 1.9
0.929
INR
0,72 - 1,24
1.1 ± 0.2
1.1 ± 0.1
0.868
aTTP (sec)
26,5 - 32,5
54.4 ± 21.3
45.0 ± 9.8
0.093
TT (sec)
16 - 25
25.8 ± 10.9
27.75± 11.9
0.734
PCT (µg/ml)
0 - 0,5
3.2 ± 2.2
2.5 ± 4.3
0.671
D-dimer (µg/ml)
< 0.5
1.7 ± 0.7
3.3± 2.8
0.153
CRP (mg/dl)
< 1.0
28.4 ± 13.0
15.4 ± 8.0
NLR
0.78 – 3.53
18.7 ± 8.9
13.1 ± 6.4
0.068
PaO2/FiO2 (mmHg)
≥ 300
98.0 ± 25.7
135.7 ± 44.4
0.116
Sat o2 (%)
95 -100
88.8 ± 8.0
80.4 ± 12.8
0.223
Discussion
SARS-CoV-2 infection has been associated with several health complications, including arterial and venous thromboembolism, inflammation, hypoxia, immobilization, and diffuse intravascular coagulation. Our histopathological findings align with those of other autopsy series of COVID-19 patients, showing DAD, microthrombi in pulmonary arterioles and capillaries, and fibrin deposition in the alveolar spaces. Tubular degenerative changes and glomerular damage in our kidney samples were also consistent with findings from other studies on deceased COVID-19 patients. Nevertheless, to the best of our knowledge, this study is the first to document the structural alterations in the fibrin network that may be associated with SARS-CoV-2 infection. The only prior study on this phenomenon was conducted by Juhlin and Shelley. In 1977, they reported the in vitro formation of fibrin asteroid bodies, which have an amorphous central region, likely composed of platelet aggregates surrounded by fine, radiating needle-like crystals. This was achieved by incubating blood samples from patients with psoriasis or vasculitis with bacterial extracts or gram-negative bacterial endotoxins. It is important to highlight three key differences between the structures observed by Juhlin and those observed in the present study. First, Juhlin's observations were made Second, PTAH staining revealed that the nuclei were composed of fibrin rather than platelets. This finding was confirmed through immunohistochemical analysis, as the nuclei showed no reaction to CD61, VWF, or Factor VIII ( Third, the structures described by Juhlin range in size from 50 µm to 200 µm, whereas those described in this article range from 12 µm to 15 µm. The results of Juhlin's study suggest that the structure of fibrin can be altered by bacterial products to adopt an asteroid shape. In light of these findings, we sought to investigate the potential correlation between bacterial co-infection and the formation of star-shaped fibrin structures in COVID-19 patients. Nevertheless, Fisher's exact test did not reveal a correlation between the fibrin pattern and the incidence of co-infection (p = 0.397). An alternative approach to explain the formation of star-shaped fibrin bodies described in our study was to explore the potential relationship between coagulation and systemic inflammation parameters with the histopathological analysis. Although coagulation parameters were statistically similar in both groups, the analysis of systemic inflammation parameters CRP and NLR showed a tendency to be higher in the group with star-shaped fibrin bodies compared to those in the group with a reticular fibrin pattern (Table 2). Although only the CRP levels reached statistical significance, this trend in inflammation parameters strongly supported the histopathological findings, which revealed the presence of star-shaped fibrin thrombi predominantly in vessels located in areas of lung tissue with marked inflammation. Therefore, it is possible to hypothesize that this pattern may be related to thrombi inflammation induced by the host's local immune response to SARS-CoV-2 infection.
Conclusion
This study reports the discovery of a star-shaped fibrin structural pattern present in pulmonary and renal thrombi of patients who died from COVID-19. However, further research is needed to investigate how these structures may contribute to disease severity and to elucidate the molecular mechanisms involved in their formation.
